Material
|
Alloy Steel |
| Model |
KP-606 |
| Ingress Protection |
IP68 |
| Application |
Suspended Hoppers |
| Capacity |
50 - 5000 Kg |
| Features |
High Accuracy & Precision |
| Output Sensitivity(FS) |
2.0 +/- 0.002 mV/V |
| Accuracy Class |
OIML R60 C3 |
| Temperature Effect on Zero |
0.001% FS/DegC |
| Temperature Effect on Output |
0.001%FS/DegC |
| Zero balance |
+/- 1% FS |
| Maximum Safe Overload |
150% FS |
| Ultimate Safe Overload |
180% FS |
| Recommended Excitation Voltage |
5 to 15V DC |
| Maximum Excitation Voltage |
15V DC |
| Insulation resistance at 50V DC |
>= 1000 M Ohm |
| Compensated Temperature Range |
-10 to +40 Deg C |
| Cable Length |
1- 20 meter |
