| Material |
Alloy Steel |
| Model |
KP-201 |
| Ingress Protection |
IP67 |
| Application |
Suspended Hoppers |
| Capacity |
200 Kg - 100000 Kg |
| Features |
High Accuracy & Precision |
| Output Sensitivity(FS) |
2.0 +/- 0.002 mV/V |
| Combined Error |
.01 |
| Creep Error (30 minutes) |
.001 |
| Accuracy Class |
OIML R60 C3 |
| Temperature Effect on Zero |
.001 |
| Temperature Effect on Output |
.001 |
| Zero balance |
+/- 1% FS |
| Maximum Safe Overload |
150% FS |
| Ultimate Safe Overload |
180% FS |
| Recommended Excitation Voltage |
9 to 12V DC |
| Maximum Excitation Voltage |
15V DC |
| Input Resistance |
750 |
| Output Resistance |
700 |
| Insulation resistance at 50V DC |
>= 3000 M Ohm |
|
Compensated Temperature Range
|
-30 to +70 Deg C |
| Load Cell Intervals (nLC)/Divisions |
3000 |
| Operating Temperature |
-20 to +70 C |
| Brands |
K.P Automation & Control |
