| Brand |
Sensortronics |
| Model |
60001 |
| Capacity |
Upto 2T |
| Material |
Nickel Alloy Steel |
| Ingress Protection |
IP68 |
| Application |
Suspended Hoppers |
| Features |
Hermetically Sealed, High Accuracy & Precision |
| Output Sensitivity(FS) |
3.0 +/- 0.003 mV/V |
| Combined Error |
0.0001% |
| Creep Error (30 minutes) |
0.001% |
| Accuracy Class |
OIML R60 C3 |
| Temperature Effect on Zero |
0.0001% |
| Temperature Effect on Output |
0.001% |
| Zero balance |
+/- 1% FS |
| Maximum Safe Overload |
150% FS |
| Ultimate Safe Overload |
180% FS |
| Recommended Excitation Voltage |
9 to 12V DC |
| Maximum Excitation Voltage |
15V DC |
| Input Resistance |
390 |
| Output Resistance |
350 |
| Insulation resistance at 50V DC |
>= 5000 M Ohm |
|
Compensated Temperature Range
|
-30 to +70 Deg C |
| Operating Temperatue Range |
-20 to +70 Deg C |
| Load Cell Intervals (nLC)/Divisions |
3000 |
| Cable Length |
5 |
